Simple use of up navigation

arr Up navigation help us use and organize our application hierarchy, Android offers built in features to implement this behavior easily. Here I present a simple use and an problem that I face while using it.

Simple use

It is easy to use, just need this in your manifest:

    android:parentActivityName=".ui.activities.MainActivity" > //<---Only add this
    <meta-data // This if you need to target Android versions lower than 16
        android:value=".ui.activities.MainActivity" />

Add android:parentActivityName="parentActivityName" to the child activity in your manifest and you are up to use it.

It will add the back arrow to your child activity and when clicked it will go to the parent activity.

You don't need to write this anymore.


public boolean onOptionsItemSelected(MenuItem item) {
    switch (item.getItemId()) {
    // Respond to the action bar's Up/Home button
        // Code to go to the parent activity
        return true;
    return super.onOptionsItemSelected(item);

You will get the same functionality for free.

The problem (parent activity recreation)

But one important think that I missed the first time I tried it, any time that you go to the parent activity using the up navigation (back arrow), the parent activity will be recreated, i.e. if it is a list you will go to the top element, if the parent activity has complex UI and images all of it will have to be recreated, worse, if the parent activity got some data from the Internet that was not cached, the whole download process will be done again. It is easy to fix this.

Why is this happening?

It is explained here Providing Up Navigation:

  • If the parent activity has launch mode , or the up intent contains FLAG_ACTIVITY_CLEAR_TOP, the parent activity is brought to the top of the stack, and receives the intent through its onNewIntent() method.
  • If the parent activity has launch mode , and the up intent does not contain FLAG_ACTIVITY_CLEAR_TOP, the parent activity is popped off the stack, and a new instance of that activity is created on top of the stack to receive the intent.


Just add launchMode="singleTop to the parent activity.



This is a small article about a simple problem in a big feature. Up navigation and launch modes are a big topic, so be careful when you use them and read the documentation understand better what happens behind the scenes
